| GS006 Asbestos composite sheet |
This product is made of GS002 and with thickness of 0.2-0.25mm perforated carbon steel sheet insertion. It have two types of both-side metal sheet and single size perforated metal sheet insertion. The material is available in Blue, Green, light-grey, black or white color. asbestos gasket sheet, asbestos gasket sheets
|
ITEM |
UNIT |
TECHNICAL DATAS |
|
Thickness Range |
mm |
1.0-3.0 |
|
Density |
G/cc |
2.2-2.5 |
|
Loss on Lgnition |
% |
24-29 |
|
Compressibility |
% |
25 +- 5 |
|
Recovery |
% |
>= 40 |
|
Tensile Strength Crosswise |
Bar |
>= 70 |
|
Thickness Increase |
Immersion |
3#Oil |
% |
>= 30 |
|
Immersion |
Oil B |
|
>= 25 |
Length: 500mm;1000mm;1200mm;1500mm
Width :500mm;1000mm Thickness:1.0 - 3.0mm
