| This is low density, high performance gasket material designed for elevated temperature applications. It is composed of a blend of asbestos fibre, inorganic fillers nitrile binder. This provides the material with good torque retentions when combined with a metal core. It's low density makes it ideally suitable for perforated core applications & the high compressibility imparts good flange conformability. This material is available in light grey, red or green shade.
Width: 500mm, 1000mm, 1200mm,
Length: 1200mm, 1350mm, 1500mm, Thickness:0.5;0.6;0.7;0.8;0.9;1.0;1.2;1.5, 3.0mm
|
PHYSICAL PROPERTIES |
Units |
Typical Value |
|
Density |
(gm/cc) |
1.1 |
|
Compressibility |
( % ) |
4-0 |
|
Recovery |
( % ) |
26 |
|
Tensile Strength |
(kg/sq.cm) |
48 |
|
FLUID IMMERSIONS |
|
|
|
|
WEIGHT INCREASE |
|
A.S.T.M. Oil 3,5hrs.150oC. |
( % ) |
49 |
|
A.S.T.M. Fuel B, 5hrs Room Temp |
( % ) |
45 |
|
50% Anti Freeze + 50% Distilled
Water 5, hrs, Room Temp. |
( % ) |
60 |
|
THICKNESS INCREASES. |
|
|
A.S.T.M. Oil 3, 5hrs 150*C. |
( % ) |
2 |
|
A.S.T.M. Fuel B, 5hrs Room Temp |
|
4 |
|
50% Anti Freeze + 50%
distilled water 5 hrs. Room Temp |
|
8 |
|
SPECIFICATION COMPLIANCE |
|
|
|
A.S.T.M. F104: 127160 E 62 M3. |
|
| |
