| BP001 Expanded graphit packing |
Expanded graphite braided packing is made from expanded pure graphite yarn, braided into packing through all kinds of technology of braiding. It can be divided into expanded graphite braided packing with inconel wire inserted, expanded graphite braided packing with fiberglass, expanded graphite braided packing impregnated with PTFE dispersion, expanded graphite braided packing with less weight loss etc. gland packing, braided packing
The products are almost suitable to all media, such as hot water, seam, acids, alkalis, organic solvents, hydrocar-bens, low temperature liquids, etc. The sealing capability is more better and safety. It is the most effective composite parts for solving problems.
gland packing, braided packing
STOCK DIMENSION:
|
mm sq. |
3.2 |
4 |
5 |
6 |
8 |
10 |
11 |
12 |
14 |
16 |
18 |
20 |
22 |
25 |
|
m/kg abt. |
75 |
50 |
33.3 |
23 |
13 |
8.3 |
7.0 |
5.6 |
4.3 |
3.4 |
2.6 |
2.2 |
1.8 |
1.4 |
|
Inch Sq. |
1/8" |
5/32" |
3/16" |
1/4" |
5/16" |
3/8" |
7/16" |
1/2" |
9/16" |
5/8" |
11/16" |
3/4" |
7/8" |
1" | APPLICATION DATAS:
|
 |
 |
 |
|
T oC |
-240oC - +650oC |
|
P bar |
500 |
|
30 |
|
V m/s |
2 |
|
2 |
|
PH |
2 - 12 | |
|
|
|
|
